BWWT8S LED tube series |
Model number | BWWT8S06-9W | BWWT8S09-16W | BWWT8S12-18W | BWWT8S15-25W |
LED type | Samsung SMD2835 |
Power | 9W | 16W | 18W | 25W |
Luminous flux | 1500lm | 2600lm | 2900lm | 4000lm |
Equivalence | 18-20W standard PHILIPS Fluorescent tube | 20-36W standard PHILIPS Fluorescent tube | 36-40W standard PHILIPS Fluorescent tube | 65-80W standard PHILIPS Fluorescent tube |
IP grade | IP65 |
Product size | 0.6m | 0.9m | 1.2m | 1.5m |
Voltage | 100-277V AC, 50/60Hz |
Luminous efficiency | 160-170LM/W |
Beam angle | 120° |
Color temperature | 2700-6500K |
CRI | Ra 85 |
LED source available | Samsung / Osram / Seoul |
Working temperature | _ 40℃～50℃ |
Working Humidity | 10%～90%RH |
Storage temperature | _40℃～80℃ |
Life expectancy | >50,000 hours |
Material | Aluminum+PC （PC housing ） |
Certificates | CE, RoHS,SAA,UL ,DLC |
Customization （ ODM )
Length options: any length cuttable ( 4.8m Max )
Diameter options: D30/D60/D80/D100/D120 ( MM )
Power options : Power flexible with length and diameter of the housing.
Dimmable options: Triac， 0-10v, PMW, DALI etc.
